Bellco Glass Bench Top Roller Apparatus, 10-Position, 230V, All-Position Drive

Description

The Bellco Digital Bench-top Roller Apparatus holds 10 glass or plastic roller bottles (110 to 120 mm diameter and up to 22.5 cm in length). The unit features a heavy-duty DC motor and solid-state electronics that operate at bottle speeds ranging from 0.3 to 10.0 rpm with the ability to select clockwise or counter clockwise direction. The digital display panel has a 0.55” LED for easy reading and the apparatus has a locking speed knob. Rollers are easily removed for replacement by using the special tool provided with each unit. All-Position Drive facilitates the use of lightweight plastic roller bottles by ensuring rotation at each bottle station, independent of any load configurations. Bellco’s unique hex-shaped shafts prevent

roller slippage for positive drive. Use of this equipment is limited to conventional laboratory mixing of roller bottles.

The Bellco 10 Position Cell Production Roller Apparatus (CPRA) is an all position drive variable speed 10 bottle roller apparatus used for the purpose of producing animal cells or cell products.  This small sized unit is ideal for experimental and pilot-scale cell culture.  The Bellco 10 Position CPRA fits Bellco Bench Top Incubators for a complete Incubated Cell Production Roller Apparatus System. Accepts Bellco Roller Bottles 110 mm & 120 mm in diameter, glass and plastic bottles up to 28cm body length.  The All-Position Drive System is a standard feature especially when using lightweight plastic bottles.  Each roller is individually driven for a precise mixing of media in roller bottles.  The unit features a heavy-duty DC motor and solid-state electronics for reliable operation. An analog tachometer displays bottle speed.  Bellco’s unique hex-shaped shafts prevent roller slippage for positive drive. Use of this equipment is limited to conventional laboratory mixing of roller bottles.

Details:

• Bottle Positions:10
• Dimensions: 73cm L X 32cm D X 37cm H (Without Bottles)
• Bottle Speed: 0.1 To 4 Rpm
• Clearance Between Decks For Bottle Placement: 134mm
• Usable Roller Length: 28cm
• Electrical Rating: 230 +/- 10vac @ 50hz Line Voltage
  1.0 Amp @ 230v, 50hz Power Consumption.
• Environmental Conditions, (Operating): Indoor Use, Pollution Degree 2, 4° To 50° C, Relative Humidity 0-90%, Non-Condensing.
• Environmental Conditions, (Non-Operating): -10° To 60° C, Degrees
  Relative Humidity 95% Maximum.

Features:

• Fits Inside Bellco Bench Top Incubators
• Accepts Bellco Glass & Plastic Roller Bottles Both 110 & 120mm Diameter Up To 28cm Overall Length.
• All Position Drive.
• Variable Speed Range.
• Analog Tachometer.
