SKC-7100 Shaker (orbital, 1" stroke)

Cat. No.
AAH30216U
https://www.scilogex.com/web/image/product.template/5821/image_1920?unique=d0b4a02
No accessories included

$ 5,352.00 5352.0 USD $ 5,352.00 In stock

$ 0.00

Currently Out-of-Stock

This combination does not exist.

Contact Us
Request a Quote



For more information please call +1 (860) 436-9221 or email us at info@scilogex.com

Share

Features

Control panel

Slide type universal platform (optional)

Progressive program operation
Programming Parameters
Max. number of segments in one (1) pattern (cycle) 20
Max. number of patterns (cycle) saved 20
Shaking motion - Forward & Backward, Pause Time 1 min. to 99 hr. 59 min.
rpm 30 to 500

Performance

  • Microprocessor PID control maintaining constant speed
  • Competitive high shaking speed up to 500 rpm.
  • Orbital shaking motion in various diameters.
    - 19mm for SKC-7075
    - 25mm for SKC-7100
    - 50mm for SKC-7200
  • Wide speed range even with heavy workload.
    - Ideal DD(Direct Drive) Brushless Motor and triple cam system support heavy load, quiet, maintenance free operation and deliver high torque at high speeds and smooth rotation.
  • Best effort run function intelligently manages its rpm to keep shaking even workload is out of its capacity.
    - Automatic shaking speed adjustment in case of excessive workload such as unbalanced load placement, unusual vibrations caused from unstable floor or external shock.
  • Pleasant test environment by the smooth acceleration and deceleration control.
    - Smooth start and smooth stop function prevent chemical spills from flasks or test tubes.
  • Exceptional low-profile design (only 12cm from bottom to platform) minimizes vibration or sliding caused by the high speed shaking motion.

Convenience

  • User friendly control panel.
    - Lab Companion’s unique VFD-bright, clear, easy to read.
    - Durable membrane touch switch and control knob.
  • Easy-exchangeable slide type universal platform reduces physical fatigue when handling the heavy load samples. (optional)
  • Repetitive task can be easily performed as the platform stops where it starts.
    - Stopping the shaking platform always at the same position is highly beneficial for automated dosing or sampling process.
  • Variety of accessories are available to meet application demands.

Safety

  • Shaking speed deviation alarm.
  • Over-current protection.


Specifications

Model SKC-7100

Control system

PID feedback control

Display

VFD

Shaking system

Motion type

Orbital

Amplitude size(mm / inch, dia)

25 / 1

Speed range2)(rpm)

30 to 500

Accuracy at 100 rpm

±1

Dimension

Platform(W×D) (mm / inch)

Small

755×520 / 29.7×20.5

Large

885×520 / 34.8×20.5

Body1)(W×D×H) (mm / inch)

754.8×662×122.2

29.7×26.1×4.8

Net weight(kg / Ibs)

75 / 165.4
Electric requirements(120V, 60Hz) 0.8A
Cat. No. AAH30216U

Permissible environmental conditions: temperature (5-40°C) and relative humidity (up to 80%).

1) Main body dimension without accessories.

2) In case of operating at high speed (350 to 500 rpm), it is recommended to use wight increaser be fixed on the working surface.

Accessories

Cat. No.:
AAA30502

Description :
SA-7001 Universal platform for SKC-7000 Series (755x520mm, needed for mounting accessories)

Accessory Type :
Universal Platform

Compatible Equipment :
SKC-7000 Shakers

Dimensions (mm / inch) :
755x520 / 29.7x20.5

Material:
304 Stainless Steel

Cat. No.:
AAA30504

Description :
SA-7002 Universal platform for SKC-7000 Series (885x520mm)

Accessory Type :
Universal Platform

Compatible Equipment :
SKC-7000 Shakers

Dimensions (mm / inch) :
885x520 / 34.8x20.5

Material:
304 Stainless Steel

Cat. No.:
AAA30513

Description :
SA-7011 Universal attachment for SKC-7000 Series(755x520mm)

Accessory Type :
Universal Attachment

Compatible Equipment :
SKC-7000 Shakers

Compatible Size (mm) :
755 x 520

Material:
Rubber

Cat. No.:
AAA30514

Description :
SA-7012 Universal attachment for SKC-7000 Series(885x520mm)

Accessory Type :
Universal Attachment

Compatible Equipment :
SKC-7000 Shakers

Compatible Size (mm) :
885 x 520

Material:
Rubber

Cat. No.:
AAA30523

Description :
SA-7021 Spring wire rack for SKC-7000 Series (755x520mm)

Accessory Type :
Spring Wire Rack

Compatible Equipment :
SKC-7000 Shakers

Compatible Size (mm) :
755 x 520

Material:
304 Stainless Steel

Cat. No.:
AAA30524

Description :
SA-7022 Spring wire rack for SKC-7000 Series (885x520mm)

Accessory Type :
Spring Wire Rack

Compatible Equipment :
SKC-7000 Shakers

Compatible Size (mm) :
885 x 520

Material:
304 Stainless Steel

Cat. No.:
AAA30533

Description :
SA-7031 Rubber mat for SKC-7000 Series (755x520mm)

Accessory Type :
Rubber Mat

Compatible Equipment :
SKC-7000 Shakers

Compatible Size (mm) :
755 x 520

Material:
304 Stainless Steel; Rubber

Cat. No.:
AAA30534

Description :
SA-7032 Rubber mat for SKC-7000 Series (885x520mm)

Accessory Type :
Rubber Mat

Compatible Equipment :
SKC-7000 Shakers

Compatible Size (mm) :
885 x 520

Material:
304 Stainless Steel; Rubber

Cat. No.:
AAA30561

Description :
SA- Weight Increaser for SKC-7000 Series

Accessory Type :
Weight Increaser

For use with :
SKC-7000 Models Shakers
