BW-20H 20L Water Bath with Agitator, 100°C

Performance

• Temperature range from ambient +5℃ to 100℃.
• Microprocessor PID control / Automatic tuning / Calibration.
• Powerful circulation system using our patented agitator.

Safety

• Two independently controlled reservoirs merged into a single unit for space saving. (for Dual models)
• Digital LED displays with quick adjustable dial knob. (0.1℃resolution)
• Streamlined design with sloped control panel for easier access and better safety.

Convenience

• Isolated design of heater, and sensor by a baffle plate to protect users and samples against direct contact.
• Complete safety protection system with warning alarms.
  - Over-temperature, over-current protection.
• Keypad lock function prevents accidental changes during operation.

Specification

• Type: Single Bath
• Bath volume (L / cu ft) 20 / 0.7
• Temperature
  - Working temp. range (℃ / ℉) Amb. +5 to 100 / Amb. +9 to 212
  - Temp. stability at 50℃ (±℃ / ℉) 0.1 / 0.18
  - Heat up time to 70℃ (min) 50
• Dimension
  - Bath opening / depth (W x L, D) (mm / inch) 498 x 300, 200 / 19.6 x 11.8, 7.9
  - Exterior (W x L x H) (mm / inch) 564 x 372 x 318 / 22.2 x 14.6 x 12.5
• Net weight (kg / lbs) 15.5 / 34.2
• Electrical requirements (120V, 60Hz, A) 8.3A
